JMT M7 Version USR-TCP232-410s Serial Ethernet Converter 400MHz RS232/RS485 to TCP/IP Server Support DHCP/Modbus TCP/RTU
Product details
| Management number | 208647129 | Release Date | 2026/03/22 | List Price | $18.39 | Model Number | 208647129 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
M7 Version USR-TCP232-410s Serial Ethernet Converter 400MHz RS232/RS485 to TCP/IP Server Support DHCP/Modbus TCP/RTU Upgraded B07C1TC165 RS232 and RS485 to Ethernet Converter USR-TCP232-410s are Modbus to Ethernet converters , or 1 RS232 and 1 RS485 serial port to Ethernet converters. Product detail: Processor: NXP Solution, Cor¡¤tex-M7 Frequency: 400MHz Power Supply: DC 5¡«36V Current: 59.7mA @12V Ethernet Port Number: 1x RJ45, 10 /100 Mbps, auto MDI/MDX, 1.5KV electromagnetic isolation. Serial Port Number: 1x RS232, DB9-male,1 x RS485, 3-pin terminal block, can work simultaneously. Baud rate: 600 bps~230.4Kbps Data Bits: 7, 8 Stop Bit(s): 1, 2 Parity Bit: None, Even, Odd. Registration Packet£ºYes Heartbeat Packet£ºYes Ethernet Packets Cache: 48KBytes Network protocol: IP,TCP,UDP,HTTP, ARP, ICMP, DHCP, DNS IP Assignment: Static/DHCP DNS Service: Yes Built-in Webpage: Yes Config Method: Built-in Webpage, Config Software, AT Command Work Mode: TCP Server/TCP client/UDP Server/UDP Client/HTTPD client WebSocket: Yes RF2217 Similar: Yes Flow Control Hardware: R¡¤TS/C¡¤TS(Only RS232) Software£ºX¡¤ON/X¡¤OFF Modbus Gateway Modbus RTU/TCP protocol conversion Multi-host polling: up to 16 hosts Package included: 1* USR-TCP232-410s serial to ethernet module 1* 140cm ¡À 3cm Female to Female Serial Cable 1* 5V Power Adater
- USR-TCP232-410s is a multi-functional serial-to-ethernet module that enables bidirectionaltransparent data transmission between Ethernet port and serial ports. B07C1TC165 Upgraded.
- USR-TCP232-410s is a dual serial port server, using the Cor¡¤tex-m7 solution, the main frequency is up to 400MHZ, with stronger performance, faster transmission speed and higher reliability.
- New AR¡¤M core , Cor¡¤tex-m7 solution , equipped with TCP/IP protocol stack, which allows users to easily complete the serial-to-ethernet conversation, saving manpower and development time, making products faster to market andenhancing com petitiveness.
- Work Mode: TCP Server/TCP client/UDP Server/UDP Client/HTTPD client.
- Config Method: Built-in Webpage, Config Software, AT Command. Network protocol: IP,TCP,UDP,HTTP, ARP, ICMP, DHCP, DNS.
| Item Weight | 1 pounds |
|---|---|
| Manufacturer | PUSR |
| Item model number | USR-TCP232-410s |
| Package Dimensions | 7.87 x 4.72 x 1.97 inches |
